Automatic Edge Banding Machine
ECE-900K (Acrylic Edgebanding)

Suitable for straight and partially inclined edges

自動貼邊機_ECE-900K (壓克力貼邊)/ Automatic Edge Banding Machine_ECE-900K (acrylic edgebanding)
Tilting Surface Forming, Pre. Fine Trimming Unit

Tilting Surface Forming, Pre. Fine Trimming Unit

  • Tilting surface forming: with chipping saw.

  • Pre. fine trimming: equipped with diamond tipped sawblade.

工作配置Working configuration

Front and Rear End Trimming units, Top and Bottom Trimming units, Top and Bottom Corner Rounding Trimming units

  • Top trimming: straight knife cutterheads x1, 1.5R profiled cutterheads x1.

  • Bottom trimming: straight knife cutterheads x1, 1.5R profiled cutterheads x1.

  • Top corner rounding trimming: 1.5R profiled cutterheads x1.

  • Bottom corner rounding trimming: 1.5R profiled cutterheads x1.

工作配置Working configuration

(Straight Edges) Gluing Device, Catalyst Coating System and Edge Pressure Rubber Belt

  • Gluing device: vertical x1.

  • Catalyst Coating System: equipped with banding catalyst applicator catalyst mist spray.

集中式面板控制器Centralized Operation Panel

Centralized Operation Panel

  • The operation panel provides a fast change between the straight edge and partially inclined edge cutting by simply turning a selection switch on the operation panel. The partially inclined edge machining mechanism will move forward or backward according to the operator's selection, which requires no further adjustment. As a result, dramatic upgrading of machining efficiency can be obtained.

工作配置Working configuration

(Partially Inclined Edges) Gluing Device, Catalyst Coating System and Edge Pressure Rubber Belt

  • Gluing device: angled x1.

  • Catalyst Coating System: equipped with banding catalyst applicator catalyst mist spray.

Feature

The well designed automatic edge banding machine from E-Chain is a multi-function machine.
Its outstanding design makes it excellent for production of cabinet door and drawer.
• Banding strips: Acrylic.
• Glue: Quick dry glue.
• Working thickness range for straight edges: 9~45mm.
• Working thickness range for partially inclined edges: 15~25mm.
• Banding strips thickness: 0.4~2mm.

Composition:

Specification :

Equipment List :
