4

SPINDLE

Double End Sizer

C-Type 4 spindle configuration

雙端裁斷機Double End Sizer   C Type
Digital Width Controller (CH-525)

Digital Width Controller
(CH-525)

Auto. positioning of movable side of machine via a digital width controller (CH-525) for auto. working width setting.
Features measurement selection in mm/inches.

Top Pressure Beams + Gearbox

Top Pressure Beams + Gearbox

Heavy top pressure beams with spring loaded rollers on which V-belts run; driven via gearbox off feed drive shaft driving bottom feed chaintracks.

Feed Chaintrack

Feed Chaintrack

Non marking, anti skid rubber surfaced bottom feed chaintracks composed of precision chains, linked by hardened and ground pins in sealed permanently lubricated needle bearings with adjustable tensioner.

Infeed Reference Fence

Infeed Reference Fence

Infeed reference fence on fixed side of machine with removable "L-shaped" guide for workpieces with top/bottom overhangs.

Heavy Duty Machine Base + Precision Linear Guideways + Lead Screw +AC Motor

Heavy Duty Machine Base + Precision Linear Guideways + Lead Screw +AC Motor

Heavy duty machine base by welded stress relieved steel. Movable side of machine runs on precision linear guideways, driven by lead screw and AC motor (with encoder).

Sizing System

Sizing System

Top and bottom saw construction may effectively avoid tearing problems when cutting laminated panels. Scoring and main sawblades are closely positioned to facilitate adjustment.
