Double End Tenoner
S-Type 6 / 8 Spindle Configuration

6

SPINDLE

Double End Tenoner

S-Type 6 Spindle Configuration

雙端作榫機Double End Tenoner S Type 6
Touch Screen

Touch Screen

Auto. positioning of movable side of machine via a touch screen and PLC for auto. working width setting.
Features a user friendly HMI with English/Chinese language and measurement selection in mm/inches.

Top pressure beams + Gearbox

Top Pressure Beams + Gearbox

Heavy top pressure beams with spring loaded rollers on which V-belts run; driven via gearbox off feed drive shaft driving bottom feed chaintracks.

Main Saw System

Main Saw System

Capable of swivelling to angles of up to ±90°.

Feed Chaintrack

Feed Chaintrack

Non marking, anti skid rubber surfaced bottom feed chaintracks composed of precision chains, linked by hardened and ground pins in sealed permanently lubricated needle bearings with adjustable tensioner.

Infeed reference fence

Infeed Reference Fence

Infeed reference fence on fixed side of machine with removable "L-shaped" guide for workpieces with top/bottom overhangs.

Moulding System

Moulding System

Capable of swiveling to angles of up to ±90°.
Powered by high frequency motor.

Heavy duty machine base + Precision Linear Guideways + Lead screw + AC motor

Heavy Duty Machine Base + Precision Linear Guideways + Lead Screw +AC Motor

Heavy duty machine base by welded stress relieved steel.
Movable side of machine runs on precision linear guideways, driven by lead screw and AC motor (with encoder).

Scoring Saw System

Scoring Saw System

Capable of swivelling to angles of up to ±90°.
Optional saw jumping function.

8

SPINDLE

Double End Tenoner

S-Type 8 Spindle Configuration

雙端作榫機Double End Tenoner S Type 8
Touch Screen

Touch Screen

Auto. positioning of movable side of machine via a touch screen and PLC for auto. working width setting.
Features a user friendly HMI with English/Chinese language and measurement selection in mm/inches.

Top pressure beams + Gearbox

Top Pressure Beams + Gearbox

Heavy top pressure beams with spring loaded rollers on which V-belts run; driven via gearbox off feed drive shaft driving bottom feed chaintracks.

Main Saw System

Main Saw System

Capable of swivelling to angles
of up to ±90°.

Feed Chaintrack

Feed Chaintrack

Non marking, anti skid rubber surfaced bottom feed chaintracks composed of precision chains, linked by hardened and ground pins in sealed permanently lubricated needle bearings with adjustable tensioner.

Infeed reference fence

Infeed Reference Fence

Infeed reference fence on fixed side of machine with removable "L-shaped" guide for workpieces with top/bottom overhangs.

First Moulding System

First Moulding System

Equipped with cutter jumping function.
Optional capability of swiveling to angles of up to 0° ~ 90°.
Powered by high frequency motors.

Heavy duty machine base + Precision Linear Guideways + Lead screw + AC motor

Heavy Duty Machine Base + Precision Linear Guideways + Lead Screw +AC Motor

Heavy duty machine base by welded stress relieved steel.
Movable side of machine runs on precision linear guideways, driven by lead screw and AC motor (with encoder).

Scoring Saw System

Scoring Saw System

Capable of swivelling to angles
of up to ±90°.
Optional saw jumping function.

Second Moulding System

Second Moulding System

Capable of swiveling to angles
of up to ±90°.
Powered by high frequency
motors.

Taiwan Branch :

Phone: +886-4-2562-0988

Fax: +886-4-2561-9826

Address: No. 276-2, Kuan Chi Road, Shen Kang District, Taichung 42948, Taiwan

E-CHAIN MACHINERY CO., LTD.
